Technique Parameter
• Applicable luminaire: LED 10-50W
• Input voltage: AC100-240V ±20% 1A， 50-60Hz；
•Output voltage: DC180-240V
•Battery compatibility: compliant with GB17743-1999, GB17625.1-1998.
•Safety: compliant with EN61347-2-7, EB61347-2-13.
• Charging Time 24hours
• Charging time: the time depends on the capability of emergent batteries.
Batteries capability (mah)/charging current (ma) = actually charging time. 85%.
• Charging protection voltage: 12.9V Discharge ending voltage: 10.8V. Discharge depth:
• Display time: 180 minutes (it is tailored according to requirement).
Technical characteristics:
1. Supply Voltage:AC100-240V,220-240V,110V 50/60HZ
2. Output Voltage: DC 180-240V
3. LED Sources: 40W max
4. Battery: Li-on, Ni-Cd
5. Max load current : 3Amp
6. Emergency switch on time:<5 Second
7. Charging time: 30H
8. Ambient temperature: 0~50°C
| NO. | INPUT VOLTAGE | LED RANGE VOLTAGE | EMERGENCY CONST POWER | SUPPLY POWER | BATTERY-mAH | DURATION TIME | REACHARGING TIME | CERTIFICATION |
| 1E3 | AC 100-240v | DC 180-240V | 20W | 20W | Li-on 11.1V 6.0AH | 180mins | 30H | CE |
| 2E3 | AC 220-240v | DC 180-240V | 30W | 30W | Li-on 11.1V 9.0AH | 180mins | 30H | CE |
| 3E3 | AC 110V | DC 180-240V | 40W | 40W | Li-on 11.1V 12.0AH | 180mins | 30H | CE |
| 1E4 | AC 100-240v | DC 180-240V | 20W | 20W | Li-on 11.1V 4.4AH | 120mins | 30H | CE |
| 2E4 | AC 220-240v | DC 180-240V | 30W | 30W | Li-on 11.1V 6.6AH | 120mins | 30H | CE |
| 3E4 | AC 110v | DC 180-240V | 40W | 40W | Li-on 11.1V 9.0AH | 120mins | 30H | CE |
