Introduction
Emergency LED Driver
A maintained emergency conversion module, consisting of a battery charger with short circuit protection and a constant current driver for operation of a single high power LED.
The module is constant voltage compliant providing reinforced insulation between the supply and battery circuit and incorporates deep discharge protection circuitry to protect the batteries.
Module is available as part of a LED Conversion Kit.
The emergency kits is a flexible solution for a changing market
• Drives a single High Power LED
• IP65 rate level
• 3 Year Warranty
Technical Details:
1.The battery charging and discharging times:>500 times;
2.Ambient Temperature range ta:0°C~+55°C
3.Max.casing temperature tc:70°C
4.Input voltage :AC 220-240V
5.Lamp: LED DC 24V
6.Battery: Li-on 14.8V 4.0AH
7.Charging time: 30H
8.Conversion time<3s
9.EM Time: 3H
10.EM Power:30w
