Technical Details:
1.The battery charging and discharging times:>500 times;
2.Ambient Temperature range ta:0°C~+55°C
3.Max.casing temperature tc:70°C
4.Fire-proof bag:40cm length
5.DC wire length: 70cm
NO. | INPUT VOLTAGE | LED RANGE VOLTAGE | EMERGENCY CONST POWER | SUPPLY POWER | BATTERY-mAH | DURATION TIME | REACHARGING TIME | CERTIFICATION |
1E3 | AC 100-240v | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
2E3 | AC 220-240v | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
3E3 | AC 110V | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
1E4 | AC 100-240v | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
2E4 | AC 220-240v | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
3E4 | AC 110v | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
Technical Details:
1.The battery charging and discharging times:>500 times;
2.Ambient Temperature range ta:0°C~+55°C
3.Max.casing temperature tc:70°C
4.Fire-proof bag:40cm length
5.DC wire length: 70cm
NO. | INPUT VOLTAGE | LED RANGE VOLTAGE | EMERGENCY CONST POWER | SUPPLY POWER | BATTERY-mAH | DURATION TIME | REACHARGING TIME | CERTIFICATION |
1E3 | AC 100-240v | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
2E3 | AC 220-240v | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
3E3 | AC 110V | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
1E4 | AC 100-240v | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
2E4 | AC 220-240v | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
3E4 | AC 110v | DC 6-80V | 5W | 6-100W | NI-CD 7.2V 2.0AH | 180mins | 30H | CE, ROSH |
