Conforms to 5266 part 1, ICEL 1001 Part 11, EN 60598-2-22-2002, EN 61347-2-7-2001 and EN 5266-1-2005.
220-230V 50Hz supply required
55mm minimum cutout
Dims: Pack length 920mm, Primary and secondary connection leads 190mm
Weight: 2.3kg
High quality 11.1 Volt 11Ah high temperature Li-on batteries
1 emergency hour operation of 150w output lumens ,either Non-maintained and Maintained on installation
Supplied pre wired in intumescent sleeve
Bi colour status LED on 540mm flying lead
Voltage: 220V-240V 50Hz / 60Hz
Output Voltage: 180-240V
Main Load: 100-150W
Battery Details: NI-CD, LI-ON, LEAD ACID
Guarantee: 1 year
IP Rating: IP65
Material: Plastic
Working Temp.: 0°C - 60°C
Extra Info: To maintain LED Lighting when total power failure occurs, based on advanced circuit design.
Unique power failure detection and efficient charge system
Discharge time - 3 hours
Compatible with LED Lamps
Emergency Pack
| NO. | INPUT VOLTAGE | LED RANGE VOLTAGE | EMERGENCY CONST POWER | SUPPLY POWER | BATTERY-mAH | DURATION TIME | REACHARGING TIME | CERTIFICATION |
| 1E4 | AC 220-240v | DC 20-80V | 100W | 50W | Li-on | custom | 36H | CE |
| 2E4 | AC 220-240v | DC 20-80V | 120W | 50W | Li-on | custom | 36H | CE |
| 3E4 | AC 220-240v | DC 20-80V | 150W | 50W | Li-on | custom | 36H | CE |
Highlight Features：
◇Suit to a wide range of external driver led light.
◇Suit maximum 200w light and has max 65w emergency power output.
◇Automatical self test, monthly test and annual test function.
Product Description
It can automatically test light chip's series and adjust the output voltage to best match between the inverter and the load, providing 25w~65w illumination customized.
We uses IC control circuit, has constant output power, isolation circuit, no-load protection feature.
