we are specially designed to be compact and small in size. With this small size advantage, it can be easily installed into various types of LED tube, led panel led downlight luminaire fittings. It is equipped with a Hi-temperature NICD/NIMH/LI-ION battery pack, test switch and a LED charge indicator. The built-in customized proprietary Hybrid IC circuitry enhances reliability and efficiency in operation
Technical Details:
1.The battery charging and discharging times:>500 times;
2.Ambient Temperature range ta:0°C~+55°C
3.Max.casing temperature tc:70°C
4.Test button and green indicator: out 30cm length
5.Battery: Li-on or Ni-Cd
NO. | INPUT VOLTAGE | LED RANGE VOLTAGE | EMERGENCY CONST POWER | SUPPLY POWER | BATTERY -AH | DURATION TIME | REACHARGING TIME | CERTIFICATION |
1E3 | AC 100-240V/220/240V | DC 180-240V | 9W | 9W | NI- CD 12V 2.7AH | 180mins | 30H | CE |
2E3 | AC 100-240V/220/240V | DC 180-240V | 18W | 18W | Li-on 11.1V 6.0AH | 180mins | 30H | CE |
3E3 | AC 100-240V/220/240V | DC 180-240V | 22W | 22W | NI- CD 12V 2.2AH | 60mins | 30H | CE |
