emergency light conversion kit for 45w led panel

Share to:

 1.The battery charging and discharging times:>500 times;
 2.Ambient Temperature range ta:0°C~+55°C
 3.Max.casing temperature tc:70°C
 4.Green indicator: out 50cm length
 5.Input voltage:AC100-240V,220-240V
 6.LED output voltage:30-70V
 7.Output emergency power: 20W max
 8.Charging time: 30H
 9.LED light power: 70W max
 10.Duration time: 180mins
 11. Battery: Li-on and Ni-Cd


No.
INPUT VOLTAGE LED RANGE VOLTAGE EMERGENCY CONST POWER SUPPLY POWER BATTERY-mAH DURATION TIME REACHARGING TIME CERTIFICATION

A
AC 100-240v/220-240V
DC 30-70V

10W

12-70W

Ni-Cd 12V 3.0AH

180mins

30H

CE

B
AC 100-240v/220-240V
DC 30-70V

15W

12-70W

Ni-Cd 12V 3.0AH

120mins

30H

CE

C
AC 100-240v/220-240V
DC 30-70V

20W

12-70W

Ni-Cd 12V 3.0AH

90mins

30H

CE

emergency light conversion kit for 45w led panel

LED EMERGENCY PACK 100% Brightness
